Goodman

Goodman R-32 4.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!

Write a Review
SKU:
BASE32186
MPN:
GLXS4BA4810
Weight:
500.00 LBS
Shipping:
Free Shipping
  • Goodman R-32 4.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 4.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 4.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 4.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
$2,825.00

Additional Discounts At Checkout On Select Items!

Description

Goodman R-32 4.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!

GLXS4BA4810 Matchup Code: F243-4C
SEER2 Cooling BTU/h Decibels Compressor Stage Compressor Type Motor Type Motor Horsepower Liquid Line Size Suction Line Size Refrigerant Charge (oz.)
14.3 48,000 73 Single Scroll PSC 1/6 3/8 7/8 91
Volts/Phase (60Hz) M.C.A. M.O.P. Min/Max Volts Net Weight (lbs.) Gross Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
208/230-1 25.2 40 197/253 211 226 35.5 35.5 35.75
GR9S800805CN
Upflow or Downflow Input Natural Gas Output LP Gas Output AFUE Temp. Rise Range (*F) Blower Wheel Diameter (in.) Blower Wheel Width (in.) Motor Horsepower Motor Speed
Upflow 80,000 64,000 64,000 80% 35-65 10 10 3/4 9
Vent Diameter (in.) No. of Burners M.C.A. M.O.P. Weight (lbs.) Dimensional Widht (in.) Dimensional Depth (in.) Dimensional Height (in.)
4 4 12.45 15 132 21 28 33
CHPTA4830C3
Tons Liquid Line Size Suction Line Size Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
3.5-4.0 3/8 7/8 78 30 21 21
GLXS4BA4810 Matchup Code: F252-6C
SEER2 Cooling BTU/h Decibels Compressor Stage Compressor Type Motor Type Motor Horsepower Liquid Line Size Suction Line Size Refrigerant Charge (oz.)
14.3 48,000 73 Single Scroll PSC 1/6 3/8 7/8 91
Volts/Phase (60Hz) M.C.A. M.O.P. Min/Max Volts Net Weight (lbs.) Gross Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
208/230-1 25.2 40 197/253 211 226 35.5 35.5 35.75
GR9S801005CN
Upflow or Downflow Input Natural Gas Output LP Gas Output AFUE Temp. Rise Range (*F) Blower Wheel Diameter (in.) Blower Wheel Width (in.) Motor Horsepower Motor Speed
Upflow 100,000 80,000 80,000 80% 35-65 10 10 3/4 9
Vent Diameter (in.) No. of Burners M.C.A. M.O.P. Weight (lbs.) Dimensional Widht (in.) Dimensional Depth (in.) Dimensional Height (in.)
4 5 12.45 15 132 21 28 33
CHPTA4830C3
Tons Liquid Line Size Suction Line Size Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
3.5-4.0 3/8 7/8 78 30 21 21
