Goodman

Goodman R-32 5.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!

Write a Review
SKU:
BASE32187
MPN:
GLXS4BA6010
Weight:
500.00 LBS
Shipping:
Free Shipping
  • Goodman R-32 5.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 5.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 5.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 5.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
$3,225.00

Additional Discounts At Checkout On Select Items!

Description

Goodman R-32 5.0 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!

GLXS4BA6010 Matchup Code: F245-9C
SEER2 Cooling BTU/h Decibels Compressor Stage Compressor Type Motor Type Motor Horsepower Liquid Line Size Suction Line Size Refrigerant Charge (oz.)
14.3 60,000 76 Single Scroll ECM 1/3 3/8 7/8 94
Volts/Phase (60Hz) M.C.A. M.O.P. Min/Max Volts Net Weight (lbs.) Gross Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
208/230-1 32.4 50 197/253 224 239 35.5 35.5 39.5
GR9S800805CN
Upflow or Downflow Input Natural Gas Output LP Gas Output AFUE Temp. Rise Range (*F) Blower Wheel Diameter (in.) Blower Wheel Width (in.) Motor Horsepower Motor Speed
Upflow 80,000 64,000 64,000 80% 35-65 10 10 3/4 9
Vent Diameter (in.) No. of Burners M.C.A. M.O.P. Weight (lbs.) Dimensional Widht (in.) Dimensional Depth (in.) Dimensional Height (in.)
4 4 12.45 15 132 21 28 33
CHPTA6030D3
Tons Liquid Line Size Suction Line Size Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
4.0-5.0 3/8 7/8 82 30 21 24.5
GLXS4BA6010 Matchup Code: F255-1C
SEER2 Cooling BTU/h Decibels Compressor Stage Compressor Type Motor Type Motor Horsepower Liquid Line Size Suction Line Size Refrigerant Charge (oz.)
14.3 60,000 76 Single Scroll ECM 1/3 3/8 7/8 94
Volts/Phase (60Hz) M.C.A. M.O.P. Min/Max Volts Net Weight (lbs.) Gross Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
208/230-1 32.4 50 197/253 224 239 35.5 35.5 39.5
GR9S801005CN
Upflow or Downflow Input Natural Gas Output LP Gas Output AFUE Temp. Rise Range (*F) Blower Wheel Diameter (in.) Blower Wheel Width (in.) Motor Horsepower Motor Speed
Upflow 100,000 80,000 80,000 80% 35-65 10 10 3/4 9
Vent Diameter (in.) No. of Burners M.C.A. M.O.P. Weight (lbs.) Dimensional Widht (in.) Dimensional Depth (in.) Dimensional Height (in.)
4 5 12.45 15 132 21 28 33
CHPTA6030D3
Tons Liquid Line Size Suction Line Size Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
4.0-5.0 3/8 7/8 82 30 21 24.5
GLXS4BA6010 Matchup Code: F278-0C
SEER2 Cooling BTU/h Decibels Compressor Stage Compressor Type Motor Type Motor Horsepower Liquid Line Size Suction Line Size Refrigerant Charge (oz.)
14.3 60,000 76 Single Scroll ECM 1/3 3/8 7/8 94
Volts/Phase (60Hz) M.C.A. M.O.P. Min/Max Volts Net Weight (lbs.) Gross Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
208/230-1 32.4 50 197/253 224 239 35.5 35.5 39.5
GR9S801205DN
Upflow or Downflow Input Natural Gas Output LP Gas Output AFUE Temp. Rise Range (*F) Blower Wheel Diameter (in.) Blower Wheel Width (in.) Motor Horsepower Motor Speed
Upflow 120,000 96,000 96,000 80% 40-70 10 10 1 9
Vent Diameter (in.) No. of Burners M.C.A. M.O.P. Weight (lbs.) Dimensional Widht (in.) Dimensional Depth (in.) Dimensional Height (in.)
4 6 15.3 20 132 24.5 28 33
CHPTA6030D3
Tons Liquid Line Size Suction Line Size Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
4.0-5.0 3/8 7/8 82 30 21 24.5
