Goodman

Goodman R-32 3.5 Ton 80% AFUE Vertical/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!

Write a Review
SKU:
BASE32162
MPN:
GLXS4BA4210
Weight:
450.00 LBS
Shipping:
Free Shipping
  • Goodman R-32 3.5 Ton 80% AFUE Vertical/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 3.5 Ton 80% AFUE Vertical/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 3.5 Ton 80% AFUE Vertical/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 3.5 Ton 80% AFUE Vertical/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
$2,613.00

Additional Discounts At Checkout On Select Items!

Description

Goodman R-32 3.5 Ton 80% AFUE Vertical/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!

GLXS4BA4210 Matchup Code: F236-3C
SEER2 Cooling BTU/h Decibels Compressor Stage Compressor Type Motor Type Motor Horsepower Liquid Line Size Suction Line Size Refrigerant Charge (oz.)
14.3 42,000 72 Single Scroll PSC 1/6 3/8 7/8 83
Volts/Phase (60Hz) M.C.A. M.O.P. Min/Max Volts Net Weight (lbs.) Gross Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
208/230-1 19 30 197/253 210 225 35.5 35.5 35.75
GR9S800805CN
Upflow or Downflow Input Natural Gas Output LP Gas Output AFUE Temp. Rise Range (*F) Blower Wheel Diameter (in.) Blower Wheel Width (in.) Motor Horsepower Motor Speed
Upflow 80,000 64,000 64,000 80% 35-65 10 10 3/4 9
Vent Diameter (in.) No. of Burners M.C.A. M.O.P. Weight (lbs.) Dimensional Widht (in.) Dimensional Depth (in.) Dimensional Height (in.)
4 4 12.45 15 132 21 28 33
CAPTA4230C3
Tons Liquid Line Size Suction Line Size Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
2.5-3.5 3/8 7/8 66 21 21 30
GLXS4BA4210 Matchup Code: F245-5C
SEER2 Cooling BTU/h Decibels Compressor Stage Compressor Type Motor Type Motor Horsepower Liquid Line Size Suction Line Size Refrigerant Charge (oz.)
14.3 42,000 72 Single Scroll PSC 1/6 3/8 7/8 83
Volts/Phase (60Hz) M.C.A. M.O.P. Min/Max Volts Net Weight (lbs.) Gross Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
208/230-1 19 30 197/253 210 225 35.5 35.5 35.75
GR9S801005CN
Upflow or Downflow Input Natural Gas Output LP Gas Output AFUE Temp. Rise Range (*F) Blower Wheel Diameter (in.) Blower Wheel Width (in.) Motor Horsepower Motor Speed
Upflow 100,000 80,000 80,000 80% 35-65 10 10 3/4 9
Vent Diameter (in.) No. of Burners M.C.A. M.O.P. Weight (lbs.) Dimensional Widht (in.) Dimensional Depth (in.) Dimensional Height (in.)
4 5 12.45 15 132 21 28 33
CAPTA4230C3
Tons Liquid Line Size Suction Line Size Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
2.5-3.5 3/8 7/8 66 21 21 30
