Goodman

Goodman R-32 2.5 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!

Write a Review
SKU:
BASE32183
MPN:
GLXS4BA3010
Weight:
350.00 LBS
Shipping:
Free Shipping
  • Goodman R-32 2.5 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 2.5 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 2.5 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
  • Goodman R-32 2.5 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!
$2,056.00

Additional Discounts At Checkout On Select Items!

Description

Goodman R-32 2.5 Ton 80% AFUE Horizontal/Upflow Gas Split System - CHOOSE YOUR BTU AND COIL MATCHUP!

GLXS4BA3010 Matchup Code: F212-8C
SEER2 Cooling BTU/h Decibels Compressor Stage Compressor Type Motor Type Motor Horsepower Liquid Line Size Suction Line Size Refrigerant Charge (oz.)
14.3 30,000 71 Single Rotary PSC 1/6 3/8 3/4 63
Volts/Phase (60Hz) M.C.A. M.O.P. Min/Max Volts Net Weight (lbs.) Gross Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
208/230-1 15 25 197/253 155 170 29 29 32
GR9S800603BN
Upflow or Downflow Input Natural Gas Output LP Gas Output AFUE Temp. Rise Range (*F) Blower Wheel Diameter (in.) Blower Wheel Width (in.) Motor Horsepower Motor Speed
Upflow 60,000 48,000 48,000 80% 20-50 10 8 1/2 9
Vent Diameter (in.) No. of Burners M.C.A. M.O.P. Weight (lbs.) Dimensional Widht (in.) Dimensional Depth (in.) Dimensional Height (in.)
4 3 8.7 15 100 17.5 28 33
CHPTA3630B3
Tons Liquid Line Size Suction Line Size Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
2.5-3.0 3/8 7/8 66 30 21 17.5
GLXS4BA3010 Matchup Code: F216-5C
SEER2 Cooling BTU/h Decibels Compressor Stage Compressor Type Motor Type Motor Horsepower Liquid Line Size Suction Line Size Refrigerant Charge (oz.)
14.3 30,000 71 Single Rotary PSC 1/6 3/8 3/4 63
Volts/Phase (60Hz) M.C.A. M.O.P. Min/Max Volts Net Weight (lbs.) Gross Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
208/230-1 15 25 197/253 155 170 29 29 32
GR9S800803BN
Upflow or Downflow Input Natural Gas Output LP Gas Output AFUE Temp. Rise Range (*F) Blower Wheel Diameter (in.) Blower Wheel Width (in.) Motor Horsepower Motor Speed
Upflow 80,000 64,000 64,000 80% 35-65 10 8 1/2 9
Vent Diameter (in.) No. of Burners M.C.A. M.O.P. Weight (lbs.) Dimensional Widht (in.) Dimensional Depth (in.) Dimensional Height (in.)
4 4 8.7 15 116 17.5 28 33
CHPTA3630B3
Tons Liquid Line Size Suction Line Size Weight (lbs.) Dimensional Width (in.) Dimensional Depth (in.) Dimensional Height (in.)
2.5-3.0 3/8 7/8 66 30 21 17.5
