The Goodman 5 Ton 14 SEER2 96% 120K BTU Upflow Gas Furnace System

The Goodman 5 Ton 14 SEER2 96% 120K BTU Upflow Gas Furnace System is designed to deliver dependable heating and cooling for larger homes and light commercial spaces. This matched system brings together three core components: the GSXN406010 air conditioner condenser, the GM9S961205DN high-efficiency gas furnace, and the CAPT4961D4 evaporator coil. Together, they form a balanced system that focuses on performance, efficiency, and long-term reliability.

This article highlights how each component works within the system and why this combination is a solid choice for properties that need strong cooling capacity and efficient gas heat.

A Detailed Look at the Complete System

This Goodman gas furnace system features a 5-ton cooling capacity and a powerful 120,000 BTU gas furnace. That makes it well-suited for larger homes where consistent comfort is a priority during both hot summers and colder months.

The three components include:

• GSXN406010 – Outdoor air conditioning condenser
• GM9S961205DN – 96% AFUE upflow gas furnace
• CAPT4961D4 – Indoor evaporator coil

Each part is engineered to work together for balanced airflow, proper refrigerant management, and dependable heating performance.

GSXN406010 Condenser: Reliable Cooling Performance

The GSXN406010 is the outdoor air conditioning unit that removes heat from your home during the cooling season. With a cooling capacity of 60,000 BTU/h and a 14.3 SEER2 efficiency rating, this condenser is built to handle heavy cooling loads while keeping energy use in check.

Key Specifications

• Cooling Capacity: 60,000 BTU/h
• SEER2 Rating: 14.3
• Sound Level: 75 dBA
• Dimensions: 35.5" W x 35.5" D x 36.5" H

Compressor and Fan Motor

This gas furnace heating system uses a single-stage scroll compressor, a proven design known for smooth operation and durability. Scroll compressors are widely used in residential systems because they provide steady cooling output with fewer moving parts than older designs.

The condenser fan motor is a PSC motor rated at 1/4 horsepower and draws 1.30 FLA. This motor helps move air across the condenser coil to efficiently release heat.

Electrical Data

• Voltage: 208/230V, single phase
• Minimum Circuit Ampacity (MCA): 33.3
• Maximum Overcurrent Protection (MOP): 50 amps
• Operating Voltage Range: 197–253 volts

These electrical requirements ensure the system can be safely integrated into residential power setups when installed by a qualified technician.

What This Means for Homeowners

With its robust capacity and proven components, the GSXN406010 provides dependable cooling for larger square-footage homes. It is designed to maintain comfort even during peak summer temperatures while operating at an efficiency level that meets current standards.

GM9S961205DN Gas Furnace: High-Efficiency Heating Power

At the heart of this system's heating side is the GM9S961205DN, a 96% AFUE upflow gas furnace. AFUE, or Annual Fuel Utilization Efficiency, measures how much of the fuel used is converted into usable heat. A 96% rating means that nearly all of the fuel goes directly into warming your home.

Furnace Specifications

• High Fire Input: 120,000 BTU
• High Fire Output: 115,320 BTU
• AFUE: 96%
• Dimensions: 24" W x 28.75" D x 34.5" H

This furnace is designed for homes that need a strong heat source, especially in colder climates or in properties with higher heating demands.

Burner and Venting

• Number of Burners: 6
• Vent Diameter: 3 inches

Multiple burners provide even heat distribution across the heat exchanger, maintaining consistent airflow and temperature throughout the system.

Circulator Blower Performance

The furnace features a powerful circulator blower designed to handle the airflow demands of a 5-ton cooling system:

• Available AC at 0.5” ESP: 3–5 tons
• Blower Wheel Size: 11" x 11"
• Horsepower: 1 HP at 1075 RPM
• Speeds: 9

This 9-speed blower motor provides installers with the flexibility to fine-tune airflow based on duct design and system requirements. Proper airflow is critical for comfort, efficiency, and system longevity.

Temperature Rise Range

• Temperature Rise: 35–65°F

This range ensures the furnace delivers warm air at safe and effective temperatures for comfort without stressing system components.

Why a 96% AFUE Furnace Matters

A high-efficiency furnace like the GM9S961205DN can significantly reduce natural gas usage compared to older, lower-efficiency units. Over time, that can translate into noticeable energy savings, especially during long heating seasons.

CAPT4961D4 Evaporator Coil: Supporting Balanced Performance

The CAPT4961D4 evaporator coil is installed indoors and works with the condenser to absorb heat from your home's air during cooling mode. It also supports heat transfer during heating when paired with the furnace.

Coil Specifications

• Nominal Size: 4–5 tons
• Dimensions: 24.5" W x 21" D x 30" H
• Liquid Line Connection: 3/8"
• Suction Line Connection: 7/8"

These line sizes match the condenser, helping ensure proper refrigerant flow and system performance.

Role in the System

The evaporator coil is where cooled air is produced before being distributed through your ductwork. A properly sized coil like the CAPT4961D4 ensures the system can reach its rated efficiency and cooling capacity without strain.

How the System Works Together

When installed as a matched system, these components function as a unified heating and cooling solution:

• The GSXN406010 condenser removes heat from indoor air during cooling.
• The CAPT4961D4 coil absorbs that heat, allowing cooled air to circulate inside.
• The GM9S961205DN furnace provides high-efficiency gas heat during winter while also housing the blower that moves air throughout the home year-round.

By matching a 5-ton condenser to a furnace capable of handling both airflow and heating demand, this system maintains balanced operation throughout the seasons.

Ideal Applications for This System

A 5-ton, 120,000 BTU system like this is typically suited for:

• Larger single-family homes
• Multi-level houses with high cooling loads
• Properties in regions with hot summers and colder winters
• Homes replacing older, less efficient HVAC systems

Correct system sizing is essential. A licensed HVAC professional should evaluate your home's square footage, insulation, layout, and local climate before installation.

Designed for Long-Term Value

This Goodman system focuses on:

• Strong cooling capacity for demanding environments
• High-efficiency gas heating to reduce fuel waste
• Durable components like scroll compressors and multi-speed blowers
• Matched sizing for consistent airflow and comfort

Together, these features support dependable performance year after year when properly installed and maintained.

Final Thoughts

The Goodman 5 Ton 14 SEER2 96% 120K BTU Upflow Gas Furnace System brings together powerful cooling, efficient heating, and carefully matched components into one complete solution. With the GSXN406010 condenser, GM9S961205DN furnace, and CAPT4961D4 coil, this system is built to meet the comfort needs of larger homes that demand reliable performance year-round.

For homeowners upgrading from older equipment or building new, this system offers a balanced approach to comfort, efficiency, and durability.
