Understanding the Matchup Options

The Goodman R-32 2.5 Ton 80% AFUE Horizontal/Upflow Gas Split System offers flexibility, allowing homeowners and contractors to choose the furnace BTU capacity that best matches the cooling system and installation needs. Rather than functioning as a single fixed configuration, this system is available in several matchups—each using the same outdoor condenser and indoor evaporator coil, paired with different gas furnaces. By reviewing these matchups, you can better understand the performance characteristics, airflow capabilities, and dimensional differences between each option.

Below is a quick breakdown of the components that appear across these matchups and how the three furnace pairings differ.

Shared Components Across All Matchups

Every configuration of this 2.5 ton split system includes the Goodman GLXS4BA3010 outdoor condenser and the CHPTA3630B3 indoor evaporator coil. These two components make up the cooling portion of the system, regardless of which furnace you select.

GLXS4BA3010 Outdoor Unit

This 2.5-ton condenser delivers 30,000 BTU/h of cooling with a 14.3 SEER2 efficiency rating and operates at 71 decibels. It uses a single-stage rotary compressor and a PSC fan motor (1/6 HP). The condenser is factory-charged with 63 oz. of R-32 refrigerant and uses standard 3/8" liquid and 3/4" suction line sizes.

Electrical specifications include:

• 208/230-1-60 operation
• 15 M.C.A. / 25 M.O.P.
• A minimum/maximum voltage range of 197/253

Physically, the unit weighs 155 lbs. net, 170 lbs. gross, and measures 29" W x 29" D x 32" H.

GLXS4BA3010 Standard Features

• Energy-efficient compressor
• Fully charged for 15 ft. of tubing
• Copper tube / enhanced aluminum fin coil (5 mm diameter)
• Factory-installed filter drier
• Sweat connection service valves with accessible gauge ports
• High-pressure switch
• Enclosed contactor
• Ground lug connection
• Long-life capacitors
• AHRI Certified
• ETL Listed

GLXS4BA3010 Cabinet Features

• Removable grille-style top (UL 60335-2-40 compliant)
• Venturi design for improved airflow velocity
• Architectural Gray powder-coat (500-hour salt-spray rated)
• Steel louver coil guard
• Wire fan discharge grille
• Top and side maintenance access
• Single-panel access with space for accessories

CHPTA3630B3 Indoor Evaporator Coil

The matching coil for all three configurations is rated for 2.5–3.0 tons. It uses:

• 3/8" liquid line
• 7/8" suction line

Additional coil details:

• Weight: 66 lbs.
• Dimensions: 30" W x 21" D x 17.5" H

System Matchup Options

Each matchup code corresponds to a different furnace paired with the shared condenser and coil. The furnaces differ primarily in heating capacity, motor horsepower, burner count, and BTU output.

? Matchup 1: F212-8C

Furnace Model: GR9S800603BN

This option pairs the cooling system with a 60,000 BTU input furnace delivering 48,000 BTU output for both natural gas and LP gas. It maintains an 80% AFUE rating.

Key furnace details include:

• Vent Diameter: 4 in
• Burners: 4
• Motor: 1/2 HP, 9-speed
• Blower Wheel: 10" diameter x 8" width
• Temperature Rise: 20–50°F
• Electrical Requirements: 8.7 M.C.A. / 15 M.O.P.
• Dimensions: 17.5" W x 28" D x 33" H
• Weight: 100 lbs.

This matchup is ideal for small to mid-size heating loads where the 2.5-ton cooling capacity pairs well with a moderate furnace output.

? Matchup 2: F216-5C

Furnace Model: GR9S800803BN

This configuration offers higher heating capacity with an 80,000 BTU input and 64,000 BTU output (for natural and LP gas), while maintaining the same 80% AFUE.

Furnace specifications include:

• Vent Diameter: 4 in
• Burners: 4
• Motor: 1/2 HP, 9-speed
• Blower Wheel: 10" x 8"
• Temperature Rise: 35–65°F
• Electrical Requirements: 8.7 M.C.A. / 15 M.O.P.
• Dimensions: 17.5" W x 28" D x 33" H
• Weight: 116 lbs.

This matchup is suited for homes needing a stronger heating output while still aligning with the 2.5-ton cooling capacity.

Why These Matchups Matter

Offering multiple furnace matchups allows contractors and homeowners to fine-tune the balance between heating output and cooling performance. The 2.5-ton cooling portion remains constant, but the heating side can be tailored to:

• Climate zone
• Home size
• Ductwork capacity
• Installation clearance
• Fuel needs

This ensures the system performs efficiently throughout the year while meeting specific placement or airflow requirements.

Final Thoughts

The Goodman R-32 2.5 Ton 80% AFUE Horizontal/Upflow Gas Split System stands out because it provides reliable cooling performance with modern R-32 refrigerant while offering flexible heating configurations. Whether you choose the moderate-capacity F212-8C or the higher-capacity F216-5C, each configuration delivers solid efficiency, dependable operation, and proven Goodman engineering backed by industry-recognized certifications.
